Modern linear guide technology, pre-loaded ball screws and advanced software.

3

Aluminum Alloy Cover make machine looks beautiful .

4

Load accuracy of +/-0.5% down to 0.4% of load cell value provides a high dynamic range, thereby reducing the number of load cells required to cover the full force range.

5

Built-in of test methods meeting international test standards.

6

Pre-load test standards for ASTM standard and ISO standard for foam test

7

All test procedure is carried out easily with our professional software

8

Test automation and batch testing

9

Test creation is provided by software

10

Multi points load is calibrated to ensure calibration is accurate

11

History track function easy to track previous test results according to date, name..etc

11

Adopt stable and reliable servo driving system and servo motor, the adjustable rate can up to 1:100000

12

Adopt high precision load cell to keep measurement more accurate and stable.

13

Automatically detection of the adjustment and calibration by electronic system and software.

14

Data acquisition system consists of or channels high precision A/D conversion channel. The maximum resolution of 1/50000

15

With the protective function of overload, over current, over voltage, displacement upper and lower limitation and emergency stop

16

Test results can be directly output, or via bmp, excel, txt...etc

17

Cables Connection is very simple

Capacity

10KN

20KN

50KN

100KN

200KN

300KN

Force Test Range

0.2%-100% F.S (0.4%-100% F.S)

Force Test Accuracy

Better than +/-0.5% of indication value

Strength Resolution

 +/-1/500000

Displacement Resolution

0.04um

Deformation Error

  +/-0.5%

Test Speed Range

0.01mm-500mm/min

    0.01mm-300mm/min

Main Frame Type

Double Column

Tension Space

600mm

Compression Space

700mm

Test Width

        400mm

  600mm

Power Supply

   110/220V, 50/60Hz

220V/380V, 50/60Hz

Dimension

780x570x1800mm

1000mm×830mm×2300mm

1050x910x2500mm

Weight

450Kg

900Kgs

1800kg
